Active optical USB-A to USB-C for long runs.
Active optical USB-A to USB-C for long runs. - 1
Active optical USB-A to USB-C for long runs. - 2
Active optical USB-A to USB-C for long runs. - 3

NORRD

Active optical USB-A to USB-C for long runs.

NC-Core-AOC-UAC-XXX

Norrd CORE AOC UAC is a USB 3.2 A-male to C-male Active Optical Cable designed for stable, high-speed USB connections over long distances in professional environments.

10 Gbps USB

USB 3.2 Gen2 data

Up to 15 m

Active optical reach

No external power

Driver-free install

Available Lengths

LengthSKU
7,5 mNC-Core-AOC-UAC-0075
10 mNC-Core-AOC-UAC-010
15 mNC-Core-AOC-UAC-015
Request Quote

Key Features

§01

Key Features

  • Active Optical USB 3.1 Gen2 cable (USB-A male to USB-C male) for long-run data
  • Up to 10 Gbps SuperSpeed performance, backwards compatible with USB 2.0 / 1.1
  • Long distance stability up to 15 m
  • Zero EMI/RF interference for reliable operation in complex environments
  • Reversible USB-C connector for easy plugging
  • Plug-and-play with no drivers or external power required
  • Supports up to 5V 900mA power delivery

Description

Norrd CORE AOC UAC is a USB 3.2 A-male to C-male Active Optical Cable designed for stable, high-speed USB connections over long distances in professional environments. By using optical fiber for the data path, it delivers full USB 3.1 Gen2 performance up to 10 Gbps across runs up to 15 meters, while remaining fully backwards compatible with USB 2.0 and 1.1 devices. The optical transmission eliminates EMI/RF interference, ensuring reliable signal quality even in electrically noisy installations. The reversible USB-C connector simplifies connections, and with true plug-and-play operation requiring no external power, it's a mature, cost-effective solution for demanding USB applications such as machine vision, remote monitoring, and AV/IT setups where distance and stability matter.

Technical Specifications

GENERAL
Cable Type
Hybrid Fiber + Copper
Available Lengths
7.5m, 10m, 15m
Plug & Play
Yes (No driver required)
Power Supply
No external power required
DATA
USB Standard
USB 3.2 Gen2x1
Max Bandwidth
10 Gbps
Backward Compatibility
USB2.0 / USB1.1
Supported OS
Windows / Mac OS / Linux
Power Delivery to Device
5V @ 900mA (Max)
Cable Power Consumption
140mW
Fiber Type
OM3
Copper AWG
20AWG + 24AWG + 28AWG
MECHANICAL
Cable OD
4.8mm ±0.15mm
Cable Color
Black
Jacket Material
LSZH
Connector Material
Die-cast Zinc Alloy
Shielding
Triple Shielded
Filler Material
Kevlar + Al Mylar
Min Bend Radius
20mm
Connector Pull Strength
15kg (150N)
Cable Pull Strength
25kg (250N)
ENVIRONMENT
EMI Resistance
High
RFI Resistance
High
Operating Temp
0°C ~ 60°C
Storage Temp
-20°C ~ 70°C
Humidity
5% – 90%
PACKING
Packaging Type
ESD Bag

Downloads

Product Datasheet

Product Datasheet

Auto-generated product datasheet (one-pager)

Download
